4 Vehicle guidance setup EZ-Pilot steering system
Aggressiveness
Setting Explanation
Online aggressiveness How aggressively the EZ-Pilot system corrects deviations from the
guidance line.
Enter a value between 50-150%.
Approach aggressiveness How fast the EZ-Pilot system steers the vehicle onto the guidance
line.
Enter a value between 50-150%
Advanced
Setting Explanation
Roll Offset Angle
Estimate Steering Angle Bias Turn on to enable the ability to drive the offline distance to zero.
Dynamic Approach Angle Turn on to have a more aggressive line acquisition.
Steering Slew Limit
For smoother steering, raise the value.
Note – A value too low will cause instability.
Steering Acceleration Limit
For smoother steering, raise the value.
Note – A value too low will cause instability.
EZ-Pilot Demo
EZ-Pilot Demo Mode is useful for practice with defining fields, coverage logging, and assisted
steering.
Note – EZ-Pilot Demo Mode requires an EZ-Pilot controller, motor, and EZ-Pilot simulator stand.
This option is available if you have loaded the vehicle demo type from the Vehicle Database (VDB).
(See Load VDB, 70.)
EZ-Pilot system calibration
Before you begin to use the display, you must calibrate the EZ-Pilot system. To do this, complete
the Quick Start Wizard (see Quick start wizard, 188), that displays the first time that you use the
display.
Note – You must have GNSS connected.
64 CFX-750 Display User Guide Version 7.0, Revision A
