Advanced display settings 12 System settings
Note – Additional equipment may be required to properly use the Digital Output function. To use
speed pulse output, you need a radar sensor cable kit that includes a pulse amplifier adapter.
Contact your local reseller.
Setting Explanation
Disabled Tap to turn digital output on or off. When disabled, digital output on
pin 2 of Port A is off.
Radar
Output simulated radar pulses at a pre-defined speed pulse output
rate. This can be useful to:
l Replace the radar/true ground speed sensor for speed on the
vehicle
l Send speed to any other agricultural device requiring speed
pulses, such as a yield monitor or variable rate controller.
After you select Radar, set the radar frequency rate from the Digital
Output screen.
Remote Output
Output a signal whenever auto steering is engaged. This can be
useful to drive a switch or relay for equipment that should be active
when engaged.
Advanced User Config
CAUTION – Do not use the Enable Advanced User Config feature unless you have the support of a Trimble
Reseller. Altering any of the settings for this feature may cause system failure.
To enable Advanced User Config, tap Enable Advanced User Config, then tap On and .
When advanced user configuration is available, the following additional settings can be accessed.
l Advanced Port Setup: Settings for Serial Port A and B
l
l Input protocol
l Output protocol
l Baud rate
l Data bits
l Data parity
l Stop bits
l Hardware Tests:Motor test
l Mapping:Set data dictionaries to default
l Clear All Passcodes: Removes all subscriptions
Version 7.0, Revision A CFX-750 Display User Guide 193
