HARDI 5500 / 6500 controller setup 5 Implement application controller setup
Swath Control
Setting Explanation
Boom control Enter a width between 1' 00" - 328' 01" (0.30 - 99.99 m).
Coverage switching overlap The amount of boom switching overlap allowed before the section
will be switched by the system.
Enter a value between 1 - 99%.
Boundary switching
overlap
The amount of overlap on a boundary before the boom section is
switched off.
Enter a value between 1 - 99%.
On/Off valve latency Tune the section switching to allow for hardware delays.
Enter a time between 0.0 - 10.0 seconds.
Intentional overlap Set a distance to be overlapped when moving to an unsprayed area
or out of a sprayed area.
Enter a distance between 0' 00" - 32' 10" (0.00 - 10.00 m).
Rate control
Setting Explanation
On Application rates are sent from a prescription loaded in the display
or the target rate manually configured on the display.
Off The target rate must be set on the HARDI controller. The CFX-750
display does not send target rates to the controller. This is the
default setting.
Note – When sending a target rate to the HARDI 5500 controller that is higher than 99.9, the
display rounds to the nearest whole number. For example, 0-99.9 is not rounded. 101.4 is rounded
to 101.
Off When Stopped
You can use this option to control whether the system allows the vehicle to continue operating
when it is not moving.
If the vehicle is a clutch-operated planter, tap No so you can continue planting even when stopped.
Version 7.0, Revision A CFX-750 Display User Guide 95
