Autopilot steering system 4 Vehicle guidance setup
2. Adjust the sensitivity level up or down by increasing or decreasing it in increments of 0.20 units.
3. Turn the steering wheel and assess whether the manual override feature is at an acceptable
sensitivity level by evaluating the effort required against the Override status on the display.
4.
Repeat Step1 through Step3 until the Calibration screen shows a suitable response.
It is recommended that you evaluate the performance of the manual override feature under
loading conditions and / or during activities that may affect the pressure of the hydraulic
system.
5.
Tap when Manual Override responds the best.
Controller Orientation
Note – NavController II images on the display represent the mounting orientation when viewed
from the top looking down, and with the front of the tractor pointing at the top of the screen.
1. Choose the type of entry you want to perform for the controller orientation:
ll Orthogonal entry: Use this option if the mounting position of the control was completed in
90° increments around the X, Y, Z axis.
l Direct entry: Use this option if the mounting position was done in known Roll, Pitch, Yaw
degrees.
2. For orthogonal entry:
a.
At the Connector Orientation screen, match the controller image on the screen to the
same orientation (mounting direction) of the NavController II wiring connectors when
viewed from above and with the front of the tractor pointing to the top of the display.
Ignore the reference direction of the NavController II labeling during this step.
When the correct connector orientation has been achieved, tap .
b.
At the Label Orientation screen, match the controller image on the screen to the same
orientation (mounting direction) of the NavController II Labeling Panel when this is viewed
from above, and with the front of the tractor pointing to the top of the display.
Ignore the reference direction of the Nav II wiring connectors during this step.
When the correct label orientation has been achieved, tap .
3.
For direct entry:
a.
Enter the mounting angles of the controller in relation to the Roll = 0, Pitch = 0, Yaw = 0
state of the controller.
The 0,0,0 state of the controller is defined with the wiring connectors facing the rear of the
Version 7.0, Revision A CFX-750 Display User Guide 71
