Trimble CFX-750 - Advanced Display Settings

12 System settings Advanced display settings
Setting Description
Main Lightbar LED Mode
Select the required LED mode. There are two modes to choose
from:
l Chase: Chase the lights to stay online. The lights represent
the swath location relative to the vehicle.
l Pull: Center the lights to stay online. The lights represent
the vehicle location relative to the swath.
Advanced display settings
At the Advanced screen, you can view and adjust:
l Save/Load Configuration
l Digital Output
l Enable and access Advanced User Configuration
l Advanced User Config
l NMEAOutput
Save/Load Configurations
After you set up your display for your current job, you can save the settings to a configuration file.
Saving a system configuration can be useful for:
l Quick setup when moving the display between vehicles or when using the same vehicle but
changing the implement or application
l Tuning the settings for improved performance and saving your improved settings
l Restoring known good settings if unwanted adjustments have been made
Setting Explanation
Load a Configuration Load a configuration from internal memory or a USBdrive.
Save Current Configuration Save the current configuration to internal memory or a USB drive.
Delete a Configuration Delete a configuration.
Note – If you tap PreUpgradeConfig, all settings are changed back to settings before your last
upgrade.
Digital Output
The CFX-750 display can generate a digital signal on pin 2 of Port A.
192 CFX-750 Display User Guide Version 7.0, Revision A
