9 Yield Monitoring setup Yield Monitoring setup
Yield Monitoring setup
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3.
At the Implement screen, tap Yield Monitor.
4.
At the Yield Monitor screen, tap Yield Monitor Wizard.
5.
At the Yield Monitor Type screen, tap the type of yield monitor you have connected and tap
.
Note – If you tap None, this removes the Yield Monitor Plugin from the Guidance screen.
6.
At the Summary screen, a summary of the hardware attached to the CFX-750 display is listed.
Tap .
7.
At the Combine Setup screen, select the Combine Make, Model, and Moisture Sensor type,
and then tap .
8.
Enter in sequence the appropriate settings for Implement Measurement and then tap .
Note – For information about implement measurement, see Field-IQ setup for implements,
119.
ll Implement Width
l Number of Rows (or sections for the header swath control)
l Overlap/Skip
l Left/Right Header offset
l Forward/Back Offset
l Allowable Side to Side coverage overlap
9. At the Yield Monitoring Setup screen, complete the settings appropriate for the vehicle and
then tap .
156 CFX-750 Display User Guide Version 7.0, Revision A
