Yield Monitoring setup 9 Yield Monitoring setup
a.
Operation Setup
Setting Explanation
Header height Sensor Enable or disable logging control, based on the
header height sensor.
Header Height
The height percentage at which logging turns on
and off.
Grain Flow Delay
The length of time the combine takes to process
grain for correct mapping of yields. This value should
be the time it takes grain to go from the header to
the grain tank.
Reset Autocut Enables the reset of swath control to full width when
header is raised and lowered
b.
Crop Setup
Setting Explanation
Commodity The commodity for the crop.
Units
Tap which units of measure will be shown on the
display for yield.
Moisture Upper Limit
The highest moisture value that will be recorded for
a crop sample.
Standard Bushel Weight The standard density for the crop being harvested.
Storage Moisture The standard moisture that wet yield will be
adjusted to for dry yield.
Paddle dimensions
Verify the length, width, and distance between the
paddles on your machine.
Note – Failure to verify these dimensions can cause
degraded performance.
Elevator pitch
Verify the pitch angle of the clean grain elevator
from the vertical and the distance of the sensors
from the rear wall.
Note – Failure to set the correct optical sensor
spacing from the rear wall can cause degraded
performance.
Version 7.0, Revision A CFX-750 Display User Guide 157
