Guidance settings 8 Mapping guidance setup
Setting Explanation
Disabled No attempt is made to keep the corners above a minimum turn radius.
If you use this mode, curves may be very tight and the auto steering
system may be unable to successfully complete the turn.
Manual Manually choose the minimum radius.
Tight turn alert threshold
The CFX-750 display alerts you when your machine is within a specified distance of a tight turn.
The threshold is set between 1 and 10. To increase the sensitivity of the alert, lower the number.
Auto U-turn detection
Auto U-turn detection operates only on FreeForm™ and adaptive curve patterns. For more
information, see Guidance settings, 146.
Setting Explanation
On Automatically detects when the vehicle has done a U-turn and generates
the next guidance line.
Off Manually controls when a path is finished. With the FreeForm pattern,
you must manually stop recording. With the adaptive curve pattern,
you must manually set the B point.
Coverage Settings
Configure Coverage Settings to suit the requirements of your system.
Coverage on/off delay
Coverage delay causes the system to delay coverage logging to match the time it takes for your flow
to start when you turn your spraying or spreading system.
Turn coverage delay on if you activate coverage logging when you enable your spreading or
spraying. Coverage delay ensures that the display is recording coverage from the actual start point
of application. You can enter a delay time between 0.0 - 10.0 seconds.
Coverage logging
Coverage logging can be recorded at speeds as low as 0.8 mph (1.3 km/h).
Version 7.0, Revision A CFX-750 Display User Guide 147
