Rawson controller setup 5 Implement application controller setup
Rawson controller setup
1. After you select Rawson as your controller, a warning message displays. Read the message
carefully, and then tap to continue.
2. At the Output Port screen, choose the port you want to configure.
3. Change the Output Port to COM or AUX to match the port on the display that the controller is
connected to.
4.
On the Rawson controller:
a. Verify the default target rate and step size and then enter these values into the CFX-750
display. To learn how to change these settings on the display, see Advanced.
b. Set the baud rate to 9600.
To enable the CFX-750 display to change the rates on the controller, you must also set the Rawson
controller to GNSS mode:
1. Turn the Rawson controller on.
2. Press the MODE button twice.
3. Press the SET button to switch the controller between GNSS and non-GNSS modes.
If you do not set the Rawson controller to use GNSS mode, the CFX-750 display will only log the
rates being used.
For more information on configuring the Rawson controller, refer to the ACCU-RATE Controller 9.2A
User Guide.
Advanced
Use the Advanced option in the Implement screen to configure:
l Boom Setup
l Swath Control
l Target Rate
l Default Rate
l Step Size
l Rate Snapping
Version 7.0, Revision A CFX-750 Display User Guide 99
