9 Yield Monitoring setup Yield Monitoring calibration
Calibration instructions
1.
Collect all calibration loads using either the speed method or cut width method.
It is highly recommended that you conduct a minimum of three calibration loads to ensure that
the system provides accurate readings for all low, medium, and high flows throughout harvest.
If you conduct a Single Load calibration, this may result in poor accuracy performance when
Harvesting outside the Flow range at which the system was initially calibrated.
2.
At the Guidance screen, tap .
3.
At the Yield Monitor Quick Access screen, tap Load Details.
4.
At the Load Details screen, tap each load button and complete the settings for each load:
a.
Scale Ticket Weight:Enter the weight and then tap .
b.
Test Weight:Enter the weight and then tap .
c.
Moisture:Enter the moisture for the load and then tap .
Note – Evaluate each load for the flow variance. Only use loads that have a low flow
variation in the calibration.
5. At the Yield Sensor Calibration screen, tap Yield Sensor Calibration .
6.
At the Load screen, confirm the loads to be used in the calibration and then tap .
7.
At the Yield Sensor Calibration screen for the load, confirm the load adjustments. Tap Yes or
No and then tap .
8.
At the next screen, choose whether you want to apply the sensor calibration to previously
recorded loads in the field (tap Yes) or not (tap No). Then tap .
A message displays stating that the current load has been calibrated successfully.
9. At the Yield Monitor Quick Access screen, tap Moisture Sensor Calibration.
10. At the Moisture Sensor Calibration screen, tap the load you want to calibrate.
11. At the load screen for the load you chose, tap Scale Ticket Moisture and enter the correct
moisture from the scale ticket. Tap Use in Calibration if you want to use the value in the
calibration and then tap .
12.
At the Moisture Sensor Calibration screen, tap Yes and then tap to confirm the calibration
adjustments.
162 CFX-750 Display User Guide Version 7.0, Revision A
