Trimble CFX-750 - Boom Height Control Calibration

7 Boom Height Control setup Boom Height Control calibration
Setting Explanation
Boom Roll Stabilizer Raise this setting to increase the boom roll stability.
Note – Raising this setting will decrease the downward speed of
the boom.
Height Error Indication
Band
This is the band for which the screen will indicate you are on-
target height.
Note – This setting is for on-screen indication and does not
affect performance.
Target Height Step The distance that the target height should change when you tap
Increase or Decrease.
Minimum Target Height The minimum height that the Target Height can be set to. On a
multi-sensor control zone, this setting is used as a minimum
height for the average of the system. For quicker performance,
set this value close to the Target Height setting.
Maximum Target Height The maximum height that the target height can be set to.
System Aggressiveness The aggressiveness for the Boom Height Control system. A
higher number is more aggressive and a lower number is less
aggressive.
Boom Height Control calibration
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3. At the Implement screen tap Boom Height Control.
4. At the Height Control screen tap Hydraulic Valve Calibration.
5. At the Hydraulic Valve Calibration screen, tap the Zone you want to calibrate.
6.
At the Zone Valve Calibration screen, tap Deadband and Slope.
Note – Make sure that you lower the center section to a lower height and level the booms
before you start the calibration procedure. If the Center or Booms are too high or too low, the
calibration may fail.
7.
At the Deadband Calibration or Slope Calibration screen, tap Engage to start the calibration.
8.
Repeat Step 5 through Step 7 until all zones are calibrated, and then tap .
144 CFX-750 Display User Guide Version 7.0, Revision A
