Overview of Field-IQ 6 Field-IQ crop input control setup
Definitions
Setting Explanation
Section A number of rows or spray nozzles that are controlled by the
Tru Count Air Clutch or Tru Count LiquiBlock valves, or boom
valves. A section can have either a single row/nozzle or
multiple rows/nozzles depending on how the system is set up.
Row The individual row unit that material comes from on the
implement. This can be controlled individually as a single row
section, or as a group with other rows in a multiple row
section.
Master Switch Box (MSB) Master on/off/jump start, auto/manual switch, rate selection,
and increment/decrement switch.
See Field-IQ master switch box, 234.
12 Section Switch Box (12SSB) Required for section control. Manually control sections/rows.
See Field-IQ master switch box, 234.
Section Control Module (SCM) Controls 12 sections/rows per module with up to 4 modules
(48 module sections / rows).
Rate and Section Control
Module
(RSCM)
Controls 12 sections and application rate for spraying,
spreading and NH3.
Rawson Control Module
(RWCM)
Controls 1 Rawson variable rate drive per module with up to 4
modules.
Implement Switch Included in planter, NH3 and strip-till platform kits.
Units of measure
Setting Type of
measure
Symbol Explanation
Seed Metric
US/Imperial
kS/ha
kS/a
Thousands of seeds per hectare
Thousands of seeds per acre
Granular seed Metric
US/Imperial
kg/ha
lbs/a
Kilograms of seed per hectare
Pounds of seed per acre
Version 7.0, Revision A CFX-750 Display User Guide 117
