13 Operations Auto steering system operation
Engage the system
Note – Before you can engage the Autopilot system, you must:
l Set up and calibrate the system.
l Open a field in the Guidance screen.
l Map an AB line.
l Position the vehicle within the configured engage limits.
To engage the system:
1. Point the nose of the vehicle toward the guidance line and drive at operational speed.
2. Engage the system by either:
ll
Tapping at the Guidance screen
l Pressing the optional remote engage foot pedal
Disengage automatically
The Autopilot automated steering system automatically disengages when:
l The vehicle is manually steered, causing a manual override.
l The vehicle is outside the configured engage limits.
l You pause the system.
l GNSS positions are lost.
l
You tap on the Guidance screen.
Disengage manually
You can manually disengage the Autopilot system by turning the steering wheel.
Check the manual override setting before you start using the system by engaging on a line and then
turning the wheel until the system disengages.
To adjust the amount of force required to disengage the system, change the Manual Override
sensitivity in the Autopilot Setup screen.
224 CFX-750 Display User Guide Version 7.0, Revision A
