EZ-Pilot steering system 4 Vehicle guidance setup
To calibrate the EZ-Pilot system at a later time:
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3.
Tap Auto Steer and then EZ-Pilot Setup.
Note – If the EZ-Pilot Setup button does not display, tap Auto Steer System Type and then tap
EZ-Pilot for your controller.
At the EZ-Pilot Setup screen, tap EZ-Pilot Calibration Wizard. The wizard steps you through:
l Vehicle measurements
l T3™ roll calibration
l Angle per turn calibration
l EZ-Pilot system calibration
Vehicle measurements
For optimum guidance, you must take accurate vehicle measurements and enter them into the
display.
Note – Do not enter calibration numbers from EZ-Guide® Plus or EZ-Steer systems. This may cause
very poor vehicle control, including swerves and/or large oscillations.
To streamline the calibration process, you may want to take the vehicle measurements and record
them for entry later on.
The techniques for taking vehicle measurements are described below. Also see EZ-Steer system
setup, 56 for information on vehicle measurements.
1. Before you take the measurements:
a. Park the vehicle on level ground.
b. Make sure that the vehicle is straight, with the centerline of the body parallel to the
wheels.
2. Take the vehicle measurements.
Version 7.0, Revision A CFX-750 Display User Guide 65
