8 Mapping guidance setup Guidance settings
Setting Explanation
Disabled Turn coverage logging off.
Manual Turn coverage logging on and off manually.
Engaged Automatically enable coverage logging when the auto steer system is
engaged.
Switch Use a remote switch to turn coverage logging on or off.
Nudge settings
Nudge settings affect how nudge adjustments work during operation.
Setting Explanation
Clear nudge at swath
end
When enabled, the display clears the nudged position each time you
change swaths.
Reset nudge When enabled, any applied nudge is cleared and all swaths return to
their original positions.
Nudge increment Each nudge moves the guidance line by this value. The default nudge
increment is 0' 1" (2.5 cm). Enter a value between 2 - 12" (3 - 30 cm).
Mapping
Use this setting to set warning distance and recording positions for point, line and area.
Warning distance
Setting a warning distance causes the system to alert you when your machine approaches a feature.
As the machine moves within the specified warning distance, a warning displays. If you have an EZ-
Pilot, EZ-Steer or Autopilot system with a sonalert connected, an audible alarm also sounds.
You can set the warning distance to between 0'00" - 984' 03" (0.0 - 300.0 m).
Recording position
Choose the point at which a feature is recorded. When your vehicle is at this point, the feature will
be recorded.
148 CFX-750 Display User Guide Version 7.0, Revision A
