4 Vehicle guidance setup EZ-Steer steering system
EZ-Steer steering system
The EZ-Steer auto steering system enables you to automatically steer your vehicle on a guidance line
or pattern you create using the CFX-750 display.
l Setup (see EZ-Steer system setup, 56)
l Calibration (see EZ-Steer system calibration, 59)
l Operation (see EZ-Steer system operation, 218)
EZ-Steer system setup
To view and adjust the settings for the EZ-Steer system:
1.
At the Guidance screen, tap .
2.
At the Settings screen, tap .
3.
Tap Auto Steer and then EZ-Steer Setup.
Note – If the EZ-Steer Setup button does not display, tap Auto Steer System Type and then
tap EZ-Steer for your controller.
4. Complete the settings for setting up the EZ-Steer system.
5. After settings are complete, calibrate the EZ-Steer system (see EZ-Steer system calibration, 59).
EZ-Steer setup is divided into these categories:
l Engage Options
l Vehicle Setup
l Aggressiveness
l Advanced
l EZ-Steer Demo
Engage Options
Setting Explanation
Minimum/Maximum
speed
Disengagement speed for the EZ-Steer system:
Minimum: between 1.0 and 15.9 mph (1.6 and 25.5 kph).
Maximum: between 1.0 and 18.0 mph (1.6 and 28.8 kph).
56 CFX-750 Display User Guide Version 7.0, Revision A
