10 GNSS setup Correction services setup
5. At the GNSSCorrection Source screen, tap RTK.
6.
At the Correction Delivery screen tap Trimble VRS Modem, and then tap .
7.
At the Device Selection screen, tap DCM300, then tap .
8. Connect the modem and turn it on.
9. Select the required Trimble modem and follow the on-screen instructions.
10.
The first screen in the VRS setup wizard is Wireless Modem Setup. This is required only for
Trimble modems if you installed a SIM card.
The SIM card provider is responsible for providing settings required.
Wireless Modem Settings Explanation
APN Mobile Network Access Point Name, usually required by the
network
GPRS User Name Mobile Network User name, optional setting . Check with
your mobile network if this setting is required
GPRS Password Mobile Network Password, optional setting. Check with
your mobile network if this setting is required
CPIN SIM PIN: Optional password lock to restrict use of the SIM
card
11.
Complete the next steps in the wizard. Enter the VRS settings provided by your Trimble
CenterPoint™ or network RTK provider.
Internet Base Settings Explanation
Server Name/Address RTK/VRS/CORS base station broadcast name
Server Port Number Server Port Number
Mount Point Base station mount point
VRS User Name Network Assigned username
VRS Password Network Assigned password
12.
After you have completed the wizard, the VRS Status screen shows the VRS connection status
and all the settings entered.
172 CFX-750 Display User Guide Version 7.0, Revision A
