Control setup for a location 6 Field-IQ crop input control setup
Setting Explanation
Shaft Encoder Constant Enter the pulse per revolution for the feedback sensor you
have connected to this module.
Gear Ratio Calculator Use the calculator to calculate the gear ratio, if required.
Gear Ratio Enter the gear ratio from the feedback sensor to the seed
disk.
Seeds Per Disk Enter the number of holes in the seed disk.
e.
At the Tank/Bin Settings screen, complete the settings for the drive and tap .
Setting Explanation
Status Tap On to enable the Tank/Bin.
Tap Off to turn the Tank/Bin setup off.
Capacity Units Select the units for the Tank/Bin.
Capacity Set the total volume for the Tank/Bin.
Current Volume Enter the current volume of material in the Tank/Bin.
Partial Refill Enter a amount that you want to use for a partial refill.
Warning Level Enter the amount of material that you want to trigger a Low
Material Warning.
Version 7.0, Revision A CFX-750 Display User Guide 135
