13 Operations Auto steering system operation
One green LED in center and two red LEDs to the left Off the guidance line. For this
pattern, if the Main Lightbar LED
Mode is set to:
l Chase: Vehicle is to the right of
the guidance line
l Pull: Vehicle is to the right of the
guidance line
228 CFX-750 Display User Guide Version 7.0, Revision A
