R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-13
Parameter conversion menu
{Z(REFL)} : Executes the impedance conversion by the reflection measurement.
{Z(TRANS)} : Executes the impedance conversion by the transmission measurement.
{Y(REFL)} : Executes the admittance conversion by the reflection measurement.
{Y(TRANS)} : Executes the admittance conversion by the transmission measurement.
{1/S} : Converts the S parameter to the reverse S parameter.
{OFF} : Turns off the conversion function.
{Z0 VALUE} : Sets the characteristics impedance (Z
0
).
Note: ρ : Reflection coefficient
T:Gain
S : Reflection coefficient or gain
Z
0
: Characteristics impedance
3
1 + ρ
1 - ρ
Conversion expression =
× Z
0
2(1-T)
T
Conversion expression =
× Z
0
1 - ρ
1 + ρ
Conversion expression =
1
Z
0
×
T
2(1-T)
Conversion expression =
×
1
Z
0
1
S
Conversion expression =
