R3765/67G Series Network Analyzer Operation Manual
7.4 RESPONSE Block
7-20
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON
CH1 CH2
SPLIT CH: ON
CH1 SUB MEAS: CH3 CH4
ON
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF
SPLIT CH: ON
CH1 SUB MEAS:
ON
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: ON
SPLIT CH: ON
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
ON
Setting conditions Layout configuration
ACTIVE CH: CH1
DUAL CH: OFF
SPLIT CH: ON
CH1 SUB MEAS:
OFF
CH2 SUB MEAS:
ON
CH1
CH4
CH2
CH1
CH1
CH3
