R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-45
Open capacitance (OPEN C
0
)[10
-15
F]
(OPEN C
1
)[10
-27
F/Hz]
(OPEN C
2
)[10
-36
F/Hz
2
]
(OPEN C
3
)[10
-45
F/Hz
3
]
The unit, [sec] is converted to the unit [m], multiplied by the speed of light.
The Setting and the Explanation
Press the [CAL] to call the calibration menu (1 of 2).
Press {CAL MENUS} to call the full calibration selection Menu.
Press {CAL KIT} to call the calibration kit menu.
Press {DEFINE STANDARD} to call the user selection menu.
User specifying menu
{PORT1 REFL.STD} : Enters the parameter of the open standard to be
connected to Port 1.
calls the open standard entry menu. (See step .)
{PORT2 REFL.STD} : Enters the parameter of the open standard to be
connected to Port 2.
Calls the open Standard entry menu. (See step .)
{PORT3 REFL STD} : Enters the parameter of the open standard that is
connected to PORT3.
Calls the OS entry menu. (See step .).
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
{PORT4 REFL STD} : Enters the parameter of the open standard that is
connected to PORT4.
Calls the OS entry menu. (See step .).
* This is available when OPT14 (a built-in 4-port test set)
is installed.
{P1 ~ P2 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 1 and Port 2.
Calls the offset entry menu. (See step .)
{P1 ~ P3 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 1 and Port 3.
Calls the offset entry menu. (See step .)
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
{P2 ~ P3 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 2 to Port 3.
Calls the offset entry menu. (See step .)
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
1
2
3
4
5
6
6
6
6
7
7
7
To Next Page
