ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-46
{P1 ~ P4 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 1 to Port 4.
Calls the offset entry menu. (See step .)
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
{P2 ~ P4 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 2 to Port 4.
Calls the offset entry menu. (See step .)
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
{P3 ~ P4 THRU.STD} : Enters the parameters of the through standard to be
connected between Port 3 to Port 4.
Calls the offset entry menu. (See step .)
* This is available when OPT11 (Built-in 3-port test set)
or OPT14 (Built-in 4-port test set) is installed.
{SAVE TO USER DEFINE}: Saves the parameters entered.
calls the saving menu. (See step .)
Open standard entry menu
{OPEN C0} : Enters the open capacitance, C
0
.
{OPEN C1} : Enters the open capacitance, C
1
.
{OPEN C2} : Enters the open capacitance, C
2
.
{OPEN C3} : Enters the open capacitance, C
3
.
{OPEN OFFSET} : Enters the electric length of the open standard.
Calls the offset entry menu. (See step .)
{SHORT OFFSET} : Enters the electric length of the short standard.
Calls the offset entry menu. (See step .)
Offset entry menu
{OFFSET DELAY} : Enters the electric length of the open/short/through
standard.
{OFFSET LOSS} : Enters the loss of the through standard.
{OFFSET Z0} : Enters the impedance of the through standard.
Saving menu
{YES} : Saves the parameters of the calibration kit.
{NO} : Does not save the parameters of the calibration kit.
7
7
7
8
6
7
7
7
8
