R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-60
(3) Operation and description
Press [CAL] to call the calibration menu (1/2).
Press {CAL MENU} to call the full calibration selection menu.
When {4 PORT FULL CAL} is pressed, the 4-port calibration is selected, then the 4-
port full calibration menu is displayed.
Press {PORT1 REFLECT’N} to call the PORT1 reflection menu.
Connect the open standard to TEST PORT1, then press {S11 (PORT1) OPEN}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the short standard to TEST PORT1, then press {S11 (PORT1) SHORT}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the load standard to TEST PORT1, then press {S11 (PORT1) LOAD}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Press {DONE PORT1 REFLECT’N} to execute the reflection calibration for TEST
PORT1.
When the reflection calibration for TEST PORT1 has been completed, the 4-port full
calibration menu is resumed.
Note: It is possible to retrieve calibration data for each calibration standard if {DONE
PORT1 REFLECT’N} has not been pressed yet.
Press {PORT2 REFLECT’N} to call the PORT2 reflection menu.
Connect the open standard to TEST PORT2, then press {S22 (PORT2) OPEN}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the short standard to TEST PORT2, then press {S22 (PORT2) SHORT}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
1
2
3
4
5
6
7
8
9
10
11
To Next Page
