R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-62
Note: It is possible to retrieve calibration data for each calibration standard if {DONE
PORT4 REFLECT’N} has not been pressed yet.
Press {TRANSMISSION} to call the transmission menu.
Connect the through standard between TEST PORT1 and TEST PORT2, then call
{P1-P2 THRU}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the through standard between TEST PORT1 and TEST PORT2, then call {P1-
P2 THRU}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the through standard between TEST PORT2 and TEST PORT3, then call
{P2-P3 THRU}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Connect the through standard between TEST PORT1 and TEST PORT4, then call
{P1-P4 THRU}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed. (Note)
Press {DONE TRANS} to execute the transmission calibration.
When the transmission calibration has been completed, the 4-port full calibration
menu is displayed.
Note: It is possible to retrieve calibration data for each calibration standard if {DONE
TRANS} has not been pressed yet.
Press {ISOLATION} to call the isolation menu.
To omit the isolation calibration, press {OMIT ISOLATION}, then press {DONE ISOLA-
TION}.:
When the isolation calibration has been completed, the 4-port full calibration menu is
displayed.
Follow directions below to execute the isolation calibration:
(31-A)Connect the load standard between TEST PORT1 and TEST PORT2, then press
{P1-P2 ISOLATION}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed.
(Note)
(31-B) Connect the load standard between TEST PORT1 and TEST PORT3, then press
{P1-P3 ISOLATION}.
A message "Wait for Sweep ." is displayed and the calibration data is acquired.
When the message disappears, the calibration data acquisition is completed.
(Note)
24
25
26
27
28
29
30
31
