R3765/67G Series Network Analyzer Operation Manual
7.10 Software Fixture Function (OPT 71/72)
7-112
TEST PORT 3.
{PORT4 DEL CIRCUIT ON/OFF}:
Selects ON/OFF of the network elimination function for
TEST PORT 4.
{LOAD DEL S2P}: Displays the network elimination file menu (see ).
Reads the user defined circuit file from the floppy disk.
{Return}: Returns to the port condition menu.
Note: Even when the network elimination function is set to ON for each port, the
function does not operate while the software fixture function is set to OFF.
Impedance conversion menu
{IMPEDANCE TRANSFORM ON/OFF}:
Selects ON/OFF of the impedance conversion function.
{PORT1 IMPEDANCE}: Sets the impedance of TEST PORT 1.
{PORT2 IMPEDANCE}: Sets the impedance of TEST PORT 2.
{PORT3 IMPEDANCE}: Sets the impedance of TEST PORT 3
{PORT4 IMPEDANCE}: Sets the impedance of TEST PORT 4.
{Return}: Returns to the port condition menu.
Note: Even when the impedance conversion function is set to ON, the function does
not operate while the software fixture function is set to OFF.
Matching circuit menu
• 1 of 4 page
{PORT1 ADD CIRCUIT ON/OFF}:
Selects ON/OFF of the matching circuit function for
TEST PORT 1.
{PORT1 ADD TYPE [ ]}: Displays the matching circuit type menu (see ).
Sets the matching circuit type of TEST PORT 1.
{PORT1 CAP C}: Sets the capacitance C of TEST PORT 1.
When "0" is entered, the capacitance is assumed to be
not connected and ignored.
{PORT1 CAP G}: Sets the conductance G for the capacitance of TEST
PORT 1.
{PORT1 IND L}: Sets the inductance L of TEST PORT 1.
When "0" is entered, the inductance is assumed to be
not connected and ignored.
{PORT1 IND R}: Set the resistance R for the inductance of TEST PORT
1.
{Return}: Returns to the port condition menu.
{More 1/4}: Moves to the 2 of 4 page.
