ADVANTEST R3765G Series

R3765/67G Series Network Analyzer Operation Manual
7.10 Software Fixture Function (OPT 71/72)
7-116
User defined circuit menu
{LOAD ADD S1P}: Displays the 1-port matching circuit file menu (see ).
This menu is used to read the user defined circuit file for
S1P data.
{LOAD ADD S2P}: Displays the 2-port matching circuit file menu (see ).
This menu is used to read the user defined circuit file for
S2P data.
{LOAD DEL S2P}: Displays the network elimination file menu (see ).
This menu is used to read the user defined circuit file for
the network elimination function.
{Return}: Returns to the software fixture menu.
1-port matching circuit file menu
{LOAD sfadd1.s1p}: Reads the 1-port matching circuit file “sfadd1.s1p” for
TEST PORT 1.
{LOAD sfadd2.s1p}: Reads the 1-port matching circuit file “sfadd2.s1p” for
TEST PORT 2.
{LOAD sfadd3.s1p}: Reads the 1-port matching circuit file “sfadd3.s1p” for
TEST PORT 3.
{LOAD sfadd4.s1p}: Reads the 1-port matching circuit file “sfadd4.s1p” for
TEST PORT 4.
{Return}: Returns to the user defined circuit menu.
2-port matching circuit file menu
{LOAD sfadd1.s2p}: Reads the 2-port matching circuit file "sfadd1.s2p" for
TEST PORT 1.
{LOAD sfadd2.s2p}: Reads the 2-port matching circuit file "sfadd2.s2p" for
TEST PORT 2.
{LOAD sfadd3.s2p}: Reads the 2-port matching circuit file "sfadd3.s2p" for
TEST PORT 3.
{LOAD sfadd4.s2p}: Reads the 2-port matching circuit file "sfadd4.s2p" for
TEST PORT 4.
{Return}: Returns to the user defined circuit menu.
Network elimination file menu
{LOAD sfdel1.s2p}: Reads the network elimination file "sfdel1.s2p" for TEST
PORT 1.
{LOAD sfdel2.s2p}: Reads the network elimination file "sfdel2.s2p" for TEST
PORT 2.
{LOAD sfdel3.s2p}: Reads the network elimination file "sfdel3.s2p" for TEST
PORT 3.
{LOAD sfdel4.s2p}: Reads the network elimination file "sfdel4.s2p" for TEST
PORT 4.
