R3765/67G Series Network Analyzer Operation Manual
7.10 Software Fixture Function (OPT 71/72)
7-115
Balance measurement menu
{MATCHING BALANCE P1}: Displays the balanced matching circuit menu (see ).
Sets the balanced matching circuit of balanced PORT 1.
{MATCHING BALANCE P2}: Displays the balanced matching circuit menu (see ).
Sets the balanced matching circuit of balanced PORT 2.
{BALANCE PARAMETER ON/OFF}:
Selects ON/OFF of the degree of balance measurement
function.
When the degree of balance measurement function is
set to ON, the MEAS menu is changed (see ).
{FLOAT BALUN ON/OFF}: Selects ON/OFF of the floating balun of the software
balun function.
When the floating balun is set to ON, the MEAS menu is
changed (see ).
{DIFF BALUN ON/OFF}: Selects ON/OFF of the differential balun of the software
balun function.
When the differential balun is set to ON, the MEAS
menu is changed (see ).
{Return}: Returns to the software fixture menu.
Note: Even when the degree of balance measurement function is set to ON, the
function does not operate while the software fixture function is set to OFF.
Balanced matching circuit menu
{BALANCE Pn C(P)-L(P)-D ON/OFF}:
Selects ON/OFF of the balanced matching circuit
function for balanced PORT n.
{BALANCE Pn CAP C}: Sets the capacitance C of balanced PORT n.
When “0” is entered, the capacitance is assumed to be
not connected and ignored.
{BALANCE Pn CAP G}: Sets the conductance G for the capacitance of balanced
PORT n.
{BALANCE Pn IND L}: Sets the inductance L of balanced PORT n.
When “0” is entered, the inductance is assumed to be
not connected and ignored.
{BALANCE Pn IND R}: Sets the resistance R for the inductance of balanced
PORT n.
{Return}: Returns to the balance measurement menu.
Note: Even when the balanced matching circuit function is set to ON, the function does
not operate while the software fixture function is set to OFF.
