R3765/67G Series Network Analyzer Operation Manual
7.10 Software Fixture Function (OPT 71/72)
7-114
• 4 of 4 page
{PORT4 ADD CIRCUIT ON/OFF}:
Selects ON/OFF of the matching circuit function for
TEST PORT 4.
{PORT4 ADD TYPE [ ]}: Displays the matching circuit type menu (see ).
Sets the matching circuit type of TEST PORT 4.
{PORT4 CAP C}: Sets the capacitance C of TEST PORT 4.
When “0” is entered, the capacitance is assumed to be
not connected and ignored.
{PORT4 CAP G}: Sets the conductance G for the capacitance of TEST
PORT 4.
{PORT4 IND L}: Sets the inductance L of TEST PORT 4.
When “0” is entered, the inductance is assumed to be
not connected and ignored.
{PORT4 IND R}: Set the resistance R for the inductance of TEST PORT
4.
{Return}: Returns to the port condition menu.
{More 4/4}: Moves to the 1 of 4 page.
Note: Even when the matching circuit function is set to ON for each port, the function
does not operate while the software fixture function is set to OFF.
Matching circuit type menu
{PORTn C(P)-L(S)-D}: Sets the matching circuit of TEST PORT n to the type of
parallel C to series L.
{PORTn L(P)-C(S)-D}: Sets the matching circuit of TEST PORT n to the type of
parallel L to series C.
{PORTn C(S)-L(P)-D}: Sets the matching circuit of TEST PORT n to the type of
series C to parallel L.
{PORTn L(S)-C(P)-D}: Sets the matching circuit of TEST PORT n to the type of
series L to parallel C.
{PORTn L(P)-C(P)-D}: Sets the matching circuit of TEST PORT n to the type of
parallel L to parallel C.
{PORTn USE CIRCUIT}: Sets the user defined circuit of TEST PORT n.
Sets the matching circuit specified by the file.
{LOAD USE CIRCUIT}: Displays the matching circuit user defined circuit menu
(see ).
Reads the user defined circuit file from the floppy disk.
{Return}: Returns to the matching circuit menu.
Note: “n” of TEST PORTn indicates the port number.
