R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-1
11 SPECIFICATIONS
This chapter describes about the function of the R3765/67G series and the performance/specification
together.
(1) Measurement Function
Sweep channel 2 channels (CH1, CH2)
Display channel 4 channels (CH1, CH2, CH3, CH4)
Trace 2 traces/channels
(Up to 8 traces can be displayed simultaneously)
Measurement parameter R3765CG/67CG: S11, S21, S12, S22
OPT11, 13: S11, S22, S33, S21, S12, S31, S13,
S23, S32
OPT14: S11, S22, S33, S44, S21, S31, S41,
S12, S32, S42, S13, S23, S43, S14,
S24, S34
R3765BG/67BG: TRANSMISSION, REFLECTION
R3765AG/67AG: A/R, B/R
These parameters can be converted into impedance (Z) or
admittance (Y).
Measurement format
Rectangular display The real part and the imaginary part of logarithmic/linear
magnitude, phase, group-delay, VSWR or complex number.
Smith chart Reading with marker is for logarithmic/linear magnitude &
phase, real part + imaginary part, R + jX, G + jB.
Polar coordinates display Reading with marker is for logarithmic/linear magnitude &
phase, real part + imaginary part.
