ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-2
(2) Signal Source Section
Frequency
Range R3765AG/BG/CG: 300kHz - 3.8GHz
R3767AG/BG/CG: 300kHz - 8GHz
Setting resolution
Measurement resolution
Accuracy
Stability against
temperature changes
Aging
1Hz
±0.01ppm
±10ppm (23°C ± 5°C)
±7.5ppm (0 to 55°C, Typical value)
±3ppm (Year, Typical value)
Output power
Range R3765CG/67CG: +10dBm to -10dBm
For OPT 12 or OPT 13
+4dBm to -16dBm
For OPT 14 +8dBm to -10dBm
For OPT 10 or OPT 10+OPT 11
+5dBm to -15dBm (ATT FIX)
+5dBm to -75dBm (ATT AUTO)
For OPT 10+OPT 12 or OPT 10+OPT 13
-1dBm to -21dBm (ATT FIX)
-1dBm to -81dBm (ATT AUTO)
For OPT 10+OPT 14
+3dBm to -15dBm (ATT FIX)
+3dBm to -75dBm (ATT AUTO)
R3765BG/67BG: +7dBm to -13dBm
For OPT 12 +9dBm to -11dBm (ATT FIX)
For OPT 10 +2dBm to -18dBm (ATT FIX)
+2dBm to -78dBm (ATT AUTO)
For OPT 10+OPT 12
+4dBm to -16dBm (ATT FIX)
+4dBm to -76dBm (ATT AUTO)
R3765AG/67AG: +17dBm to -3dBm
For OPT 10 +12dBm to -8dBm (ATT FIX)
+12dBm to -68dBm (ATT AUTO)
Resolution 0.01dB
