ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-7
(3) Characteristic of the Receiver Part
Resolution bandwidth 20kHz to 10Hz (changeable at 1, 1.5, 2, 3, 4, 5 and 7 steps)
Stability
Trace noise 0.003dBrms (300kHz to 2.6GHz, RBW 3kHz, Typical value)
0.006dBrms (2.6GHz to 3.8GHz, RBW 3kHz, Typical value)
0.012dBrms (3.8GHz to 8.0GHz, RBW 3kHz, Typical value)
For OPT 12 or 13
0.014dBrms (300kHz to 2.6GHz, RBW 3kHz, Typical value)
0.022dBrms (2.6GHz to 3.8GHz, RBW 3kHz, Typical value)
Stability against
temperature changes
0.01dB/°C (300kHz to 2.6GHz, Typical value)
0.02dB/°C (2.6GHz to 8.0GHz, Typical value)
Aging stability 0.005dB/week (Typical value)
Magnitude characteristic
Magnitude resolution 0.001dB
Frequency characteristic ±1.0dB (23°C ± 5°C)
Dynamic accuracy In reference to the value 20 dB below the allowable input
level
±0.20dB (0dB to -10dB, 300kHz to 3.8GHz)
±0.40dB (0dB to -10dB, 3.8GHz to 8.0GHz)
±0.05dB (-10dB to -50dB)
±0.10dB (-50dB to -60dB)
±0.40dB (-60dB to -70dB)
±1.00dB (-70dB to -90dB)
For R3765 BG with OPT 12 installed, 0 dB for an input of +9
dBm in reference to -32 dB
0.05dB (-12dB to -42dB)
0.2dB (-42dB to -52dB)
0.7dB (-52dB to -62dB)
2.0dB (-62dB to -72dB)
For R3765CG with OPT 12 or 13 installed, 0 dB for an input
of +4 dBm in reference to -32 dB
0.2dB (0dB to -12dB) (Typical value)
0.05dB (-12dB to -42dB)
0.2dB (-42dB to -52dB)
0.7dB (-52dB to -62dB)
2.0dB (-62dB to -72dB)
