R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-6
Signal purity
Harmonic distortion 20dBc (23°C ± 5°C when maximum output)
Non harmonic spurious 30 dBc (For the maximum output, > 1 MHz offset at 23°C to
±5°C)
Phase noise
(10kHz off)
85dBc/Hz (300kHz to 40MHz, 23°C ± 5°C)
85dBc/Hz-20Log (f/40MHz) (40MHz to 8GHz, 23°C ± 5°C)
Sweep function
Sweep type Linear, logarithmic, program or power sweep
Sweep time 0.15ms/1 point
Measurement point 3, 6, 11, 21, 51, 101, 201, 301, 401, 601, 801, 1201 point
Sweep trigger Continuous, single, hold or external triggering
Attenuation accuracy R3765AG/BG/CG, R3767AG/BG/CG
For OPT 10, OPT 10 + OPT 11/12/13/14
Attenuation 20dB
±4dB (Attenuation=0dB reference, 23°C ± 5°C)
Attenuation 40dB
±5dB (Attenuation=0dB reference, 23°C ± 5°C)
Attenuation 60dB
±6dB (Attenuation=0dB reference, 23°C ± 5°C)
(Continued)
