11 SPECIFICATIONS
11-5
R3765BG/67BG:
300kHz to 15MHz
±0.4dB (-8dBm to +2dBm, -3dBm reference 23°C ± 5°C)
±0.8dB (-13dBm to +7dBm, -3dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.2dB (-8dBm to +2dBm, -3dBm reference 23°C ± 5°C)
±0.4dB (-13dBm to +7dBm, -3dBm reference 23°C ± 5°C)
For OPT 10
300kHz to 15MHz
±0.6dB (-13dBm to -3dBm, -8dBm reference 23°C ± 5°C)
±1.3dB (-18dBm to +2dBm, -8dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.4dB (-13dBm to -3dBm, -8dBm reference 23°C ± 5°C)
±0.6dB (-18dBm to +2dBm, -8dBm reference 23°C ± 5°C)
For OPT 12
300kHz to 15MHz
±0.4dB (-6dBm to +4dBm, -1dBm reference 23°C ± 5°C)
±0.8dB (-11dBm to +9dBm, -1dBm reference 23°C ± 5°C)
15MHz to 3.8GHz
±0.2dB (-6dBm to +4dBm, -1dBm reference 23°C ± 5°C)
±0.4dB (-11dBm to +9dBm, -1dBm reference 23°C ± 5°C)
For OPT 10+OPT 12
300kHz to 15MHz
±0.6dB (-11dBm to -1dBm, -6dBm reference 23°C ± 5°C)
±1.3dB (-16dBm to +4dBm, -6dBm reference 23°C ± 5°C)
15MHz to 3.8GHz
±0.4dB (-11dBm to -1dBm, -6dBm reference 23°C ± 5°C)
±0.6dB (-16dBm to +4dBm, -6dBm reference 23°C ± 5°C)
If OPT 10 is installed, the accuracy is specified using
an attenuation of 0 dB.
R3765AG/67AG:
300kHz to 15MHz
±0.4dB (+2dBm to +12dBm, 7dBm reference 23°C ± 5°C)
±0.8dB (-3dBm to +17dBm, 7dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.2dB (+2dBm to +12dBm, 7dBm reference 23°C ± 5°C)
±0.4dB (-3dBm to +17dBm, 7dBm reference 23°C ± 5°C)
For OPT 10
300kHz to 15MHz
±0.6dB (-3dBm to +7dBm, +2dBm reference 23°C ± 5°C)
±1.3dB (-8dBm to +12dBm, +2dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.4dB (-3dBm to +7dBm, +2dBm reference 23°C ± 5°C)
±0.6dB (-8dBm to +12dBm, +2dBm reference 23°C ± 5°C)
If OPT 10 is installed, the accuracy is specified using
an attenuation of 0 dB.
(Continued)
