R3765/67G Series Network Analyzer Operation Manual
11 SPECIFICATIONS
11-4
Linearity R3765CG/67CG:
300kHz to 15MHz
±0.4dB (-5dBm to +5dBm, 0dBm reference 23°C ± 5°C)
±0.8dB (-10dBm to +10dBm, 0dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.2dB (-5dBm to +5dBm, 0dBm reference 23°C ± 5°C)
±0.4dB (-10dBm to +10dBm, 0dBm reference 23°C ± 5°C)
For OPT 10 or OPT 10+OPT 11
300kHz to 15MHz
±0.6dB (-10dBm to 0dBm, -5dBm reference 23°C ± 5°C)
±1.3dB (-15dBm to +5dBm, -5dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.4dB (-10dBm to 0dBm, -5dBm reference 23°C ± 5°C)
±0.6dB (-15dBm to +5dBm, -5dBm reference 23°C ± 5°C)
For OPT 12 or 13
300kHz to 15MHz
±0.4dB (-11dBm to -1dBm, -6dBm reference 23°C ± 5°C)
±0.8dB (-16dBm to +4dBm, -6dBm reference 23°C ± 5°C)
15MHz to 3.8GHz
±0.2dB (-11dBm to -1dBm, -6dBm reference 23°C ± 5°C)
±0.4dB (-16dBm to +4dBm, -6dBm reference 23°C ± 5°C)
For OPT 14
300kHz to 15MHz
±0.4dB (-5dBm to +5dBm, 0dBm reference 23°C ± 5°C)
±0.8dB (-10dBm to +8dBm, 0dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.2dB (-5dBm to +5dBm, 0dBm reference 23°C ± 5°C)
±0.4dB (-10dBm to +8dBm, 0dBm reference 23°C ± 5°C)
For OPT 10+OPT 12 or OPT 10+OPT 13
300kHz to 15MHz
±0.6dB (-16dBm to -6dBm, -11dBm reference 23°C ± 5°C)
±1.3dB (-21dBm to -1dBm, -11dBm reference 23°C ± 5°C)
15MHz to 3.8GHz
±0.4dB (-16dBm to -6dBm, -11dBm reference 23°C ± 5°C)
±0.6dB (-21dBm to -1dBm, -11dBm reference 23°C ± 5°C)
For OPT 10+OPT 14
300kHz to 15MHz
±0.6dB (-10dBm to 0dBm, -5dBm reference 23°C ± 5°C)
±1.3dB (-15dBm to +3dBm, -5dBm reference 23°C ± 5°C)
15MHz to 8GHz
±0.4dB (-10dBm to 0dBm, -5dBm reference 23°C ± 5°C)
±0.6dB (-15dBm to +3dBm, -5dBm reference 23°C ± 5°C)
If OPT 10 is installed, the accuracy is specified using
an attenuation of 0 dB.
(Continued)
