ADVANTEST R3765G Series

R3765/67G Series Network Analyzer Operation Manual
A.3 Initial Setting
A-8
* 5: Logarithmic magnitude (the value per division of Y-axis)
*
6:
Logarithmic magnitude (reference position)
Type Channel CH1 CH2 CH3 CH4
AG 10dB 10dB 10dB 10dB
BG 10dB 10dB 1 UNIT 10dB
CG 10dB 10dB 1 UNIT 10dB
Type Channel CH1 CH2 CH3 CH4
AG 90% 90% 90% 90%
BG 90% 90% - 90%
CG 90% 90% - 90%
