4.4 Initial Setup
4-5
* 1 : Output level
* 2 : Start/Stop level
* 3 : Selection item of input port
Type
Power on or preset *RST
AG 0dBm 0dBm
BG 0dBm 0dBm
CG, CG+OPT11 10dBm 10dBm
CG+OPT10,
CG+OPT10+OPT11
5dBm 5dBm
CG+OPT12/13 4dBm 4dBm
CG+OPT10+OPT12/13 -1dBm -1dBm
CG+OPT10+OPT14 3dBm 3dBm
CG+OPT14 8dBm 8dBm
Type
Power on or preset *RST
Start Stop Start Stop
AG -3dBm 0dBm -3dBm 17dBm
AG+OPT10 -8dBm 0dBm -8dBm 12dBm
BG -13dBm 0dBm -13dBm 7dBm
BG+OPT10 -18dBm 0dBm -18dBm 2dBm
BG+12 -11dBm 0dBm -11dBm 9dBm
BG+OPT10+OPT12 -16dBm 0dBm -16dBm 4dBm
CG, CG+OPT11/14 -10dBm 0dBm -10dBm 10dBm
CG+OPT12/13 -16dBm 0dBm -16dBm 4dBm
CG+OPT10,
CG+OPT10+OPT11/14
-15dBm 0dBm -15dBm 5dBm
CG+OPT10+OPT12/13 -21dBm -1dBm -21dBm -1dBm
Type
CH1 CH2 CH3 CH4
AG
A/R
B/R A/R
B/R
BG REFLECTION TRANSMISSION REFLECTION TRANSMISSION
CG S
11
S
21
S
11
S
21
