ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
4.4 Initial Setup
4-6
* 4 : Measurement format
* 5 : Logarithmic magnitude (the value per division of Y-axis)
* 6 : Logarithmic magnitude (reference position)
Type
CH1 CH2 CH3 CH4
AG LOG MAG LOG MAG LOG MAG LOG MAG
BG LOG MAG LOG MAG POLAR LOG MAG
CG LOG MAG LOG MAG POLAR LOG MAG
Type
CH1 CH2 CH3 CH4
AG 10dB 10dB 1dB 1dB
BG 5dB 10dB 1 UNIT 1dB
CG 5dB 10dB 1 UNIT 1dB
Type
CH1 CH2 CH3 CH4
AG 90% 90% 90% 90%
BG 90% 90% - 90%
CG 90% 90% - 90%
