ATD2 10511 - Database Edit Dialog Box

Creating database points
ADM003GVAE1005 95
Database Edit dialog box
CURRENT
DATABASE
SYSTEM
The Current Database System displays the system database
on which the Database Point list is based
ACTIVE LEVELS The Active Levels field displays the number of database tag
levels for the selected database
DATABASE
BUTTON
The Database button allows the user to select an alternate
FuelsManager database to configure
POINT NAME
AND POINT LIST
The Point Name and the Point List display the tagname for
the currently selected database point. The icon at the left of
the point list defines the type of point.
Users can search for known database point names by typing
in the tagname in the Point Name field
PREV LEVEL
AND NEXT
LEVEL
The Prev Level and Next Level buttons allow the user to
navigate up and down through the FuelsManager database
tree. The user can also move down to the next level by
double-clicking on the point in the point list
SELECT The Select button picks the current point and closes the
Database Edit dialog box. This option is only applicable
when the Database Edit dialog is opened from Operate or
CommManager
CLOSE The Close button closes the Database Edit dialog box
EDIT The Edit button opens the Edit Point dialog box for the
selected point. The format of the Edit point dialog box differs
depending on the type of point selected
NEW The New button opens the Add Point dialog box, allowing
the user to select the type of database point to be created
COPY The Copy button opens the Point Copy / Rename dialog box,
allowing the user to either make a copy of the selected point
or rename the selected point
DELETE The Delete button deletes the selected point
EXPORT The Export button opens the Import / Export Data Type
dialog box, allowing the user to select which particular data
is to be exported to a CSV formatted file
IMPORT The Import button opens the Import / Export Data Type
dialog box, allowing the user to select which particular data
is to be import from a CSV formatted file
