Draw application

ADM003GVAE1005 171

Setting the default font

Setting the default text color

Note! The Text Color &

Background Box displays your new

choice of color. This color remains

the same until the default is

changed.

Setting the default background mode

Setting the default background color

Setting the default pen attributes

Step-by-Step

• From the Attributes menu select Text Font

• The Select Text Font dialog box appears

• Select the desired font, size, and attributes

• This default applies to any text created such as labels and values

Step-by-Step

• From the Attributes menu select Text Color

• The Set Default Text Color dialog box appears

• Selecting Palette from the Set Default Text Color dialog box displays all the

colors available

• This default applies to any text created such as labels and values

Step-by-Step

• From the Attributes menu select Background Mode to display a cascading

• A check mark appears next to the current default mode

• Notice how the Text Color & Background Box display changes when you

choose transparent

Step-by-Step

• From the Attributes menu select Background Color to display the Set

Default Background Color dialog box

• Selecting Palette from the Set Default Background Color dialog box displays

all the colors available for the background color

• Notice the change in color in the Text Color & Background Box

Step-by-Step

• From the Attributes menu select Pen Attributes

• Assign a palette color

• Select a line type - invisible, dashed or dotted

• Change the line width

• The change is displayed in the Pen & Brush Box
