Managing report files
ADM003GVAE1005 215
Editing report objects
Note! You cannot move a table to
another page or outside the
margins.
Note! A label created in a table
cannot be moved outside the table
in a Summary report.
Note! You cannot move a line past
the positions of adjacent lines.
These procedures apply to both Summary and Dynamic reports. Follow the
appropriate procedure.
Managing report files
Once you save a report, the next step is to generate the report so it can be
available for printing and display in the Operate program. Generating a report
converts it into a format that can be understood by ReportManager and Operate.
Saving reports
All report files are located in the Report subdirectory of your project directory.
Generated report files contain the *.RRT file extension and saved report files
contain the *.RPT file extension.
• <Ctrl + S> or Select from the Edit menu option to be placed in edit mode
• Click on the object to be edited, the border of the object becomes dashed
to indicate it has been selected
• <Ctrl +A> or Attribute from the Edit menu. A dialog specific to the selected
object appears. This dialog is the same as the one used to create the
object; refer to the previous sections that detail the creation process
• To delete an object, select Delete from the Edit menu or <Ctrl + Del>
• To move an object, click and hold the mouse button while dragging it to the
new location
• To resize a cell in a table, position the cursor over the line (horizontal or
vertical). The cursor changes to a double-headed arrow. Click and drag the
line to the new position
Step-by-Step
• Select File and click Save As
• The Save Report dialog box appears
• Type in the Filename plus the “.RPT” report extension
• Click OK
