Point format
The storage formats available only to Input and Output points are listed below. All Tank points are of a fixed data
format.
STORAGE TYPE FORMAT RANGE
Character 8 Bit Signed -128 to 127
Byte 8 Bit Unsigned 0 to 255
Short 6 Bit Signed -32768 to 32767
Word 16 Bit Unsigned 0 to 65535
Coded 16 Bit, Index to Coded Variable 0 to 65535
Long 32 Bit Signed -2,147,483,648 to 2,147,483,647
Dword 32 Bit Unsigned 0 to 4,294,967,295
Float 4 Byte Floating Point 3.4 E ±38 (7 digits)
Double 8 Byte Double Precision Floating Point 1.7 E ± 308 (15 digits)
Time & Date 8 Byte Time & Date NA
Time 8 Byte Time Only NA
Date 8 Byte Date Only NA
User Defined String 16 Bit Index to User String 0 to 65535
