Sealing the Point in 8130 RTU
The 8130 RTU is configured via a tool called ViewRTU. ViewRTU can
communicate with the RTU either local (running on a laptop device) or remotely
running via FuelsManager’s interface connection.
The ViewRTU configuration tool allows the W&M official to apply a ‘software seal’
to a particular point. Once this seal is applied all parameters that affect the
integrity of the point’s data cannot be changed, without removing the seal.
Parameters that effect the data integrity are specific to the point type, table 1.1
(below) details this relationship.
Table 1.1
Point Type WMSeal Parameters Sealed Parameter Description
E+H FMR 131 Micropilot No
Enraf 811 Yes Module
Chan
CIU
Addr
ID
TOI
ScanCmd
LevelUnits
TempUnits
LevelDeadband
TempDeadband
External Module Address Channel for
Communications
CIU Address
Tank Gauge ID
Type of Instrument
Scan Commands for Instrument
F=ft; M=Meters; m=millimeters
F=Fahrenheit;
C=CelsiusChange of State (COS) Level
Deadband.
Change of State (COS) Temp Deadband.
Enraf 818 STIC No
Enraf 854 Yes Module
Chan
CIU
Addr
ID
TOI
ScanCmd
LevelUnits
TempUnits
LevelDeadband
TempDeadband
External Module Address
Channel for Communications
CIU Address
Tank Gauge ID
Type of Instrument
Scan Commands for Instrument
F=ft; M=Meters; m=millimeters
F=Fahrenheit; C=CelsiusK=kg/m
3
; A=API;
L=lbs/ft
3
Change of State (COS) Level Deadband.
Change of State (COS) Temp Deadband.
Enraf 867 STIC No
