Typical Tank Calculation
ADM003GVAE1005 315
Typical Tank Calculation
Analytical and Measured Data
Tank Point Configuration Parameters
Level (ft-in-16) 12-3-12
Water Level (ft-in-16) 0-9-5
Solids Level (ft-in-16) 0-1-3
%BS&W 0
Product Temperature (°F) 75.6
Product Density (lbs /US Gal) 6.8
Density Temperature (°F) 70.8
Standard Density 5 (lbs / US Gal) 6.84
Ambient Temperature (°F) 56.2
Volume Correction Method API °F: Table 6B/5B
Floating Roof Type Roof Mass Not in Strap
Roof Mass (lbs) 589
Tank Shell Material Mild Steel (Coeff of Expansion =
1.24 x 10
-5
)
Tank Insulated No
Maximum Fill Volume (US Gal) 850,000.00
Minimum Empty Volume (US Gal) 150,000.00
