Importing and exporting points
Files consisting of Input, Output, Triggered, and Tank point information can be
imported and exported. FuelsManager also enables the user to import manual
values, calculated values, forced values, strap tables, and source assignments.
This feature has been provided so that the user can create an Input, Output
Triggered, or Tank point using external applications such as Excel or Notepad. Not
only can this method save time involved in initial configuration, but it can also be
used as a backup utility or a method for making bulk changes to the configuration.
Creating a *.csv file involves entering the column headers and entering the
associated point parameters. These files can only exist as comma delimited files
(*.csv).
The parameters found in the file vary based on the type of data exported. The file
types are described in the following table:
Import / Export Data Type dialog box
INPUT POINTS Files contain all the attributes associated with an Input point
OUTPUT
POINTS
Files contain all the attributes associated with an Output
point
TRIGGER
POINTS
Files contain all the attributes associated with a Triggered
point
TANK POINTS Files contain all the attributes associated with a Tank point
STRAP TABLES Files contain tank and strap table file names
SOURCE
ASSIGNMENTS
Files contain the Database tag, variable, data source type,
database system, interfaces, device, and connected I/O
communication point entries. For example:
Tank-1.Low-Stop,VALUE,NONE
Tank-1.Gauge,LEVEL,COMM,\\GRAY1,TSU 1,Tank 1,Level,
Tank-1.Gauge,TEMP,COMM,\\GRAY1,TSU 1,Tank
1,Temperature,
Tank-1.Gauge,DENSITY,CALC
Tank-1.Gauge,LVL_H20,MANUAL
MANUAL
VALUES
Files contain the Database tag, variable, and value entries.
The value is an assigned command, for example - STOP
Tankfarm.Tank.A301,BSW,0
Tankfarm.Tank.A301,STD_DENS,67.10898
FORCED
VALUES
Files contain Database tag, variable, and value entries. The
value is a forced value. For example
Area42.Tank37,LEVEL,220
CALC VALUES Files contain Database tag, variable, and value entries. The
value is the calculated value. Uncalculated points contain the
* Uninitialized * parameter. for Example
Tank-2.Gauge,FLOW,* Uninitialized *
Tank-3.Gauge,DENSITY,75.87801
