ATD2 10511 - Edit Tank Data Dialog Box - General Tab

FuelsManager Defense
108 Administrator Manual
Edit Tank Data dialog box - General tab
DESCRIPTION Enter a descriptive name to be used for the point. This
name can be displayed on user graphics and reports, in
addition, it forms part of the alarm entry if an alarm
condition should occur.
TAG CATEGORY Each database point can be assigned a Tag Category,
which works with the Security module to determine the
level of access for the viewing and changing of database
point values.
DISPLAY QUALITY
DATA
Enable or disable the display of FuelsManager quality
information (text superscripts displayed in graphic and
reports that define from where the data was derived). The
default setting is unchecked i.e. quality data is displayed.
DETAIL Enter the name of the tank detail template (without the file
extension) to be used for this tank. If this entry is left blank
the default tank detail as defined in the registry will be
used.
VARIABLE TYPE
COLUMN
This column displays the types of tank point variables
available. This data is for display purposes only.
MINIMUM /
MAXIMUM
COLUMNS
Edit the minimum and maximum scaling ranges for each
of the variable types. The scaling ranges are used for bar
graphs and trend plots and to define the ranges used by
Operator Commands.
ENGINEERING
UNITS COLUMN
To edit the units, click on the cell containing the units you
want to change, the drop down list presented displays
only units applicable to the variable type selected.
Following a change in engineering units, FuelsManager
will ask the user if the scaling limit and alarm limits should
be automatically modified to reflect the new units.
