Sample LPG calculation
Stored Data
Calibration (7 points only) m
3
Coefficients of thermal expansion (mild steel):
Youngs modulus:
Float data:
mm
mm
3
H(1) = 0 V(1) = 0
H(2) = 2000 V(2) = 29.213
H(3) = 2500 V(3) = 42.217
H(4) = 3000 V(4) = 56.311
H(5) = 3500 V(5) = 70.627
H(6) = 4000 V(6) = 84.122
H(7) = 6000 V(7) = 114.211
Total tank volume
VT = 114.211 m
3
Gauge wire αW = 0.000017 /°C
Gauge meeting αM = 0.000017 /°C
Tank Shell αT = 0.000017 /°C
YOUNG
2.06 x 10
6
bar
Mass (m) 1033.5 g
Diameter (d) 288 mm
Density of
Liquid of
Time of
Calibration
(DENL1) 999.1
kg/m
3
