Scaling and engineering units data
ADM003GVAE1005 361
Scaling and engineering units data
Scaling and Engineering Units Data
VARIABLE TYPE
FuelsManager variables are divided into eleven types, for each type of variable the user can configure the range
of the data and the engineering units. The range and engineering units are configured via the General tab of the
tank configuration dialog box. The range information is used as the default minimum / maximum values for
display objects like bar graphs and trends, in addition to the minimum / maximum values for operator command
dialog boxes
LEVEL MININIUM - TANK MINIMUM LEVEL SCALING
This variable is the minimum range for the level, water level, solids level, and gauge position process variables.
This variable can be viewed from the Operate interface but cannot be modified
LEVEL MAXIMIUM - TANK MAXIMUM LEVEL SCALING
This variable is the maximum range for the level, water level, solids level, and gauge position process variables.
This variable can be viewed from the Operate interface but cannot be modified
LEVEL MININIUM EMPTY - MINIMUM TANK EMPTY LEVEL
This variable is the minimum level to which the tank can be safely drained. This variable is entered when
configuring the tank point, it can viewed but cannot be modified via Operate
LEVEL MAXIMUM FILL - MAXIMUM TANK FILL LEVEL
This variable is the maximum level to which the tank can be safely filled. This variable is entered when
configuring the tank point, it can be viewed but cannot be modified via Operate
LEVEL UNITS - LEVEL ENGINEERING UNITS
This variable is the engineering units for the level, water level, solids level, and gauge position process
variables. This variable can be viewed from the Operate interface but cannot be modified
TEMPERATURE MININIUM - TANK MINIMUM TEMP SCALING
This variable is the minimum range for the tank temperature, ambient temperature, and vapor temperature
process variables. This variable can be viewed from the Operate interface but cannot be modified
TEMPERATURE MAXIMIUM - TANK MAXIMUM TEMP SCALING
This variable is the maximum range for the tank temperature, ambient temperature and vapor temperature
process variables. This variable can be viewed from the Operate interface but cannot be modified
TEMPERATURE UNITS- TEMPERATURE ENGINEERING UNITS
This variable is the engineering units for the tank temperature, ambient temperature and vapor temperature
process variables. This variable can be viewed from the Operate interface but cannot be modified
VOLUME MININIUM - TANK MINIMUM VOLUME SCALING
This variable is the minimum range for all tank volume process variables. This variable can be viewed from the
Operate interface but cannot be modified
