Drawing a polyline
The Polyline tool draws multiple connected lines grouped as a single object.
Drawing a rectangle
The Rectangle tool draws rectangles and squares.
Drawing a polygon
Use the Polygon tool to draw polygons (multi-sided closed objects). The user can
create polygons with up to 25 points (24 clicks).
Drawing an ellipse
The Ellipse tool draws ellipses and circles.
Step-by-Step
• Select the Polyline tool (or select Add and click Polyline)
• Click on area to define first point
• Move the cross-hair cursor to the next point and click again
• As you move and click, the polyline appears. Clicking the right mouse button
deletes the last line segment
Note! Holding down the SHIFT key while drawing forces orthogonal movement of the line (vertical,
horizontal or at 45 degrees from previous point)
• Repeat above step for each additional point
• After the last point, press the ENTER key to complete the polyline
Step-by-Step
• Select the Rectangle tool (or select Add and click Rectangle). Click on area
to define the first corner
• Drag the cursor and release the mouse button at desired size
Note! To draw a square, follow the procedure for drawing a rectangle, but hold down the Ctrl key while
you drag the cursor
Step-by-Step
• Select the Polygon tool (or select Add and click Polygon). Click on area to
define first point
• Move the cross-hair cursor to the next point and click again.
• Repeat this step for each additional point of the polygon. Holding the SHIFT
key while drawing forces orthogonal movement of the line from the previous
point
• Press Enter to connect the last point and the first point
Step-by-Step
• Select the Ellipse tool (or select Add and click Ellipse)
• Click on area to define center point and hold down the mouse button
• Drag the cursor in a diagonal direction to create the ellipse
• Release the mouse button at desired size and shape
Note! To draw a circle, follow the procedure for drawing an ellipse, except hold down the Ctrl key while
you drag the cursor
