FuelsManager Defense
352 Administrator Manual
Product Transfer Data
Product Transfer Data
TRANSFER MODE - TANK TRANSFER MODE
This process variable is the mode by which the operator wants to transfer product to/ from tank, possible values
are inactive, by volume, by level, or by differential volume. This variable is used as part of the tank transfer
feature and as part of the Product Movement System (option). This variable is normally entered by the operator,
but can be linked to automatic tank gauging systems to allow remote setting of the transfer mode
TANK COMMAND - TANK MODE COMMAND OUTPUT
This process variable is the desired mode of operation of the tank, possible values are stop, fill, empty, run, test,
reset, or out of service. This variable is used by the tank point to enable tank mode alarms. For example, if the
tank mode is Stop (and the product movement alarms are enabled) and the level changes, then activate an
illegal movement alarm. This variable is normally entered by the operator, but can be linked to automatic tank
gauging systems to allow remote setting of the mode or can be calculated by FuelsManager based on the flow
process variable
TANK STATUS - CURRENT TANK MODE
This process variable reflects the selected mode of operation of the tank, possible values are stopped, filling,
emptying, running, testing, or disabled. This variable always reflects the selected tank mode regardless data
source selection
TRANSFER STATUS - TANK TRANSFER STATUS
This process variable reflects the current state of the tank transfer, possible values are Inactive, Trans SD
Setpoint, In Progress, Advisory or Complete. The value is intended to represent the various steps in the transfer
process. This variable always reflects the current state of the tank transfer regardless data source selection
TRANS SD SETPOINT - TRANSFER SHUTDOWN SETPOINT
This variable is the operator entered desired ending point of a tank transfer, it is automatically expressed in
either volume of level units depending on the transfer mode selected
TRANS ADV. SETPOINT - TRANSFER ADVISORY SETPOINT
This variable is the amount of time before a transfer is complete that an advisory alarm should be triggered. The
value can be from 0-120 minutes before the transfer reaches the Transfer Shutdown Setpoint
TRANSFER UNITS - TRANSFER SHUTDOWN SP UNITS
This variable is the units being used for the currently active transfer. The units are dependant on the transfer
mode selected (i.e. Xfr by Level - Tank Level Units; Xfr by Diff Vol - Tank Volume units)
TRANSFER VOLUME - CURRENT VOLUME TRANSFERRED
This variable is the amount of volume transferred into or out of a tank during the tank transfer, or the amount
transferred thus far if a transfer is active
TRANSFER TOTAL - CURRENT TRANSFERRED BASED ON MODE
This variable is the amount of volume / level / mass transferred into or out of a tank during the tank transfer, or
the amount transferred thus far if a transfer is active. Units are based on the selected transfer mode
